Elecoat UC-4H UV High Hardness Electrodeposition Coating
Elecoat UC-4H UV High Hardness Electrodeposition Coating
Rapidly improved strength for UV coatings and improved chemical resistance
SST and alkali resistance, problems with cation UV, has been greatly improved.
Compared to a conventional product (UC-2000), UV irradiance levels are 25% decreased
SST and alkali resistance, problems with cation UV, has been greatly improved.
Compared to a conventional product (UC-2000), UV irradiance levels are 25% decreased
Elecoat UC-4H UV High Hardness Electrodeposition Coating image2
Basic performance
Evaluation conditions: Ni plating substrate, 10μm (no chromate)
Red indicates improved functioning compared to conventional product (UC-2000)
|
Evaluation item: Coating (Irradiance level) |
This product （3000mJ） |
Our conventional products （4000mJ） |
Method of Experimentation |
|
|---|---|---|---|---|
| Pencil hardness (scratches) | 4H | H- | JIS K 5400 | |
| Adhesion | 100/100（9） | 100/100（5） | JIS K 5400 | |
| Alkali resistance | 96Hr | 24Hr |
5% NaOH solution, 25℃ (75°F) |
|
| Acid resistance | 500Hr | 96Hr |
5% H2SO4 solution, 25℃ (75°F) |
|
| Resistance to hot water | 4Hr | 4Hr |
Hot water (70℃, 160°F), solution |
|
| Salt Spray Test | (Ni) | 360Hr | 48Hr | JIS H 8617 |
| (brass) | 96Hr | 48Hr | ||
| CASS Test | (Ni) | 168Hr | 72Hr | JIS H 8617 |
| (brass) | 72Hr | 24Hr | ||
| Alcohol resistance | 50times | 40times | 500g load | |
| RCA | 200times | 10times | 175g load | |
